The Panasonic BT-LH2550 is a 26″ widescreen monitor designed for broadcast and studio applications. The LCD has sophisticated technology to improve upon color space while utilizing advanced processing technology which can reproduce color and contrast qualities exceeding traditional CRT monitors. The model is also capable of displaying HDTV formats and frame rates along with NTSC and PAL systems.
- Video System NTSC/PAL
- Picture Elements 1920 x 1200
- Input and Output Connectors Composite: BNC (x2 Input with Loop-Through Output) Component: BNCx3 (x2 Input with Loop-Through Output) Sync/HD: BNC (x2 Input with
- Loop-Through Output) VD: BNC (x2 Input with Loop-Through Output) SDI: BNC (x3 Input with Switched-out Connector) DVI: DVI-D with HDCP (x1 Input) Audio: Stereo Pinjack
- (x2 Input) Headphone: Stereo Mini Jack (x1 Output) RS-232C Remote: 9-Pin DSub (x1 Input)
- Picture Controls Brightness Color
- Remote Control RS-232C, GPI
- Viewing Angle 178°
- Power Requirements 100-240VAC, 50/60Hz 11-17VDC
- Power Consumption 1.6A Dimensions (WxHxD) With Stand 59.9 x 44 x 22cm Without Stand 59.9 x 41 x 10cm Weight With Stand 9.7kg Without Stand 8.2kg
Includes Roadcase
